- Sku: 036250
- Vendor: QUICK
ANCHOR WORKER QUICK GENIUS GP2 12V
Horizontal anchor worker suitable for 6-9m/ 20-29 ft boats
Anodized aluminum
Rope and chain in a single chain reel
- Integrated sensor for chain counter
- Manual Free-Fall system
- Waterproof IP66
On Deck
- Anodized Reducer
- Waterproof Motor IP66
- Stainless Steel Base AISI 316
- Internal Motor
- Chain, Rope on the same drum
Anchor worker suitable for boats 8-12m/ 26-39ft
Specifications 800W Anchor winch suitable for boats 8-12m/ 26-39ft 8MM CHAIN
|
800W |
|
|
Trend |
12V |
|
Maximum Traction |
900 Kg / 1984 lb |
|
Maximum Load |
350 Kg / 772 lb |
|
Workload |
120 Kg / 265 lb |
|
Load |
96 A |
|
Maximum Chain Speed |
29.6 m/min / 97.1 ft/min |
|
Maximum Chain Speed @ Working Load (2) |
20 m/min / 65.6 ft/min |
|
Weight |
10.2 Kg / 22.4 lb |
Specifications 500W Horizontal anchor winder suitable for boats 6-9m/ 20-29 ft 6MM CHAIN
|
Force |
500W |
|
Trend |
12V |
|
Maximum traction |
680 Kg / 1499 lb |
|
Maximum Load |
250 Kg / 551 lb |
|
Workload |
85 Kg / 187 lbs |
|
Load |
76 A |
|
Maximum Chain Speed |
25.5 m/min / 83.7 ft/min |
|
Maximum Chain Speed @ Working Load |
10.3 m/min / 33.8 ft/min |
|
Weight |
10.9 Kg / 24 lbs |
ANCHOR WORKER QUICK GENIUS GP2 12V
